Ogre - Fermented Plum

Bikepacking – Doubletrack - Exploration

$1,699.00 USD

~~$1,699.00 USD~~ $1,699.00 USD

Sale

Size Small Medium Large X-Large

Quantity

Warning for Residents of California

⚠️ WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

View full details

A Versatile All-Season Commuter Bike

If you’re like us, your bike needs likely change by the day, week, month or year. Quite the adaptable little beast, Ogre can get you to your job during the week, then way out of town on the weekend. It’s not sluggish on pavement or gravel and can also hold its own on singletrack.

Ogre is designed to be the ultimate steel utility vehicle. It relishes in those “take-the-long-way-home-and-find-some-beverages-along-the-way” sort of commutes. Snow, sleet or sweltering humidity, this is an ideal year-round commuter bike. You can also haul enough crap on it that you don’t even have to go home if you don’t want to.

All the barnacles you could ever possibly ask for including rack and fender, multiple three-pack mounts and mid-blade.
Gnot-Boost rear spacing with Rohloff torque arm slot and Bill/Ted trailer mount
Clearance for 29” x 2.5” or 27.5" x 2.8" tires with fenders

Specifications

Build Kit

Frameset

Frame

100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated

Color

Fermented Plum

Fork

100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated

Components

Headset

Cane Creek 40

Seatpost Clamp

Surly Stainless 30.0

Seatpost

Promax SP-2016, 27.2 x 300mm

Stem

Promax DA-296

Grips/Bar Tape

Velo Black

Saddle

WTB Volt

Handlebar

Salsa Bend

Drivetrain

Front Derailleur

N/A

Rear Derailleur

Microshift Advent X

Cassette

Microshift Advent X, 11-48t, 10-spd

Chain

KMC X10

Crankset

SRAM NX, 32T

Shifter

Microshift Advent X

Brake Levers

Tektro HD-M275/HD-M276

Brake Calipers

Tektro HD-M275/HD-M276

Bottom Bracket

SRAM Powerspline

Rotors

Tekro 160mm F/R, 6-Bolt

Wheels

Front Tire

Surly ExtraTerrestrial 29 x 2.5" 60tpi, Tubeless Ready (Slate wall)

Rear Tire

Surly ExtraTerrestrial 29 x 2.5" 60tpi, Tubeless Ready (Slate wall)

Front Hub

Novatec QR 9 x 100mm, 32h

Rear Hub

Novatec TA 12 x 142mm, 32h

Spoke

14g Black

Rim

WTB ST i30, 2.0 TCS, 32h

*Specifications are subject to change without notice

Geometry

Size	Small	Medium	Large	X-Large
A. Effective Top Tube	575.0	595.0	615.0	640.0
B. Stand Over	763.5	795.7	824.5	857.85
C. Reach	395.5	410.5	427.6	447.0
D. Stack	592.0	603.4	613.0	632.0
E. Total Seat Tube Length	406.4	457.2	508.0	558.0
F. Headtube Length	110.0	120.0	130.0	150.0
G. Headtube Angle	71.5	72.0	72.0	72.0
H. Seat Tube Angle	73.0	73.0	73.0	73.0
I. BB Drop	68.0	68.0	68.0	68.0
K. Chainstay Length	440.0	440.0	440.0	440.0
L. Fork Length Axle to Crown	445.0	445.0	445.0	445.0
M. Fork Offset	45.0	45.0	45.0	45.0
N. Wheelbase	1049.4	1064.5	1084.6	1110.0
Crank Arm Length	170.0	175.0	175.0	175.0
Handlebar Width	700.0	740.0	740.0	740.0
Recommended Rider Height
Stem Length	70.0	80.0	90.0	100.0

Frame Specs

Design Wheel/Tire Sizes 29 x 2.5"
Alternate Wheel/Tire Sizes 27.5 x 3.0"
Frame Construction 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Fork Construction 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
Suspension Fork Length (Travel) N/A
Rigid Fork Length 445mm
Fork Offset 45mm
Axle to Crown 445mm
Rear Spacing "Gnot-Boost" 145mm
Rear Axle Size 12 x 142mm or 12 x 148mm (axle included)
Front Brake (Rotor) Disc - 51mm I.S. (203mm max rotor)
Headset - Upper EC34/28.6
Headset - Lower EC34/30
Front Spacing 10 x 100mm
Steerer Tube Ø28.6mm (1-1/8")
Crown Race Ø30mm (1-1/8")
Stem Clamp Ø28.6mm (1-1/8")
Seatpost Ø27.2mm
Dropper Post Compatible No internal routing
Seatpost Clamp Ø30mm
Front Derailleur Clamp Ø31.8mm
Front Derailleur Type High direct mount top-pull (Ø31.8mm) / 26mm offset adapter (not included) for 142 or 135mm rear hub spacing / 29mm offset adapter (not included) for 148mm rear hub spacing
Bottom Bracket 73mm threaded (1.37" x 24TPI)
Crankset (Max Ring) 1x (Mtn): 42T / 2x (Mtn): 34/46T / 3x (Mtn): 24/36/48T / 1x (Boost): 46T / 2x (Boost): 42/48T
Accessory Mounts Dedicated Rohloff cable routing and mount for OEM 2 axle plate / Dedicated Surly Trailer mounts
Bottle Mounts 2 Three-Pack (XS-SM) / 1 Standard + 2 Three-Pack (MD - XL)
Fork Mounts 2 Four-Pack / Rack mounts: (upper, lower, and mid-blade threaded)
Front Fender Mounts Yes
Rear Fender Mounts Yes

Documents

Warranty

Frame Warranty

LIMITED WARRANTY

This Surly product is warranted against defects in materials and
workmanship for three years from the date of retail purchase of the
product, subject to the limitations detailed below. Save your dated
receipt for proof of purchase.

This warranty does NOT cover the following:

Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler

Products that have been modified, neglected, used in competition or
for commercial purposes, misused or abused, involved in accidents or
anything other than normal use

Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold

Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product

Normal wear and tear

Labor required to remove and/or refit and re-adjust the product within the bicycle assembly

This limited warranty is expressly limited to the repair or
replacement of a defective product, at the option of Surly, and is the
sole remedy of the warranty. This limited warranty applies only to the
original purchaser of the Surly product and is not transferrable. This
warranty applies only to products purchased through an authorized dealer
or distributor. In no event shall Surly be liable for any loss,
inconvenience or damage, whether direct, incidental, consequential, or
otherwise resulting from breach of any express or implied warranty or
condition, of merchantability, fitness for a particular purpose, or
otherwise with respect to our products except as set forth herein.

This limited warranty gives the consumer specific legal rights, and
those rights and other rights may vary from place to place. This limited
warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE
AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS
INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
