Krampus

Krampus

⚠️ WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

View full details

Krampus is the evolution of the 29er. It’s not a fat bike. True, its got 3” tires on 50mm rims (we call this combination “29+”). But where fat bikes are really designed for slow-speed crawling, Krampus’s frame (geometry, tubing diameter/thickness) has been designed with a long toptube and as short a rear end as we could get away with given the wheel/tire size. This, when combined with the big, wide tires, results in a mad amount of rolling inertia and grip. It rips and responds well to body English. The big tires also offer a bit of suspension-like cushion. Krampus is a trail bike that also tackles all kinds of terrain. Krampus lives somewhere between bushwhacking, speed racing, and back lot dirt track riding, and all this makes it just plain fun to ride.

Krampus’s hub spacing is standard 100mm front and 135mm rear, with rear-loading horizontal dropouts that accommodate a derailleur and single ring/cog drivetrains. It’s got clearance for disc rotors up to 185mm and is designed to run a high direct mount standard front derailleur. This type of derailleur will allow the most clearance at the tire. Even though there is no need for the sort of frame offset you find on our Pugsley and Moonlander models, chain and derailleur clearance at the tire remains a serious consideration. If you plan to use standard width rims and tires, you’ll be able to run a normal mountain triple crank. However, if you go with our 50mm Rabbit Hole rims and 3˝ Knard tires (and why wouldn’t you?) then plan to use a 1x or 2x crank…a triple simply won’t clear the tire. For best chain/tire clearance, we recommend either a Surly O.D. 2x crank or a 1x system. Other brands’ 2x cranks will work but may cause some chain-on-tire rub in the easiest gear combo.

Got all that? O.K., then. Give it the juice and hang on.

Specifications

Geometry

Geometry Diagram
SIZE S M L XL
Reach 404 426 448 470
Stack 593 602 612 621
Head Tube Angle 69° 69° 69° 69°
Head Tube Length 90 100 110 120
Seat Tube Length 375.0 425.0 475.5 525.0
BB Drop 65 65 65 65
Wheelbase 1086.8 1112.6 1138.3 1164
Chainstay Length 435 435 435 435
Top Tube Length, Actual 556.8 573 595.1 621.8
Top Tube Length, Effective 585 610 635 660
Seat Tube Angle 73° 73° 73° 73°
Standover Height 770 797 825 854
Fork Length 483 483 483 483
Fork Rake 47 47 47 47

Frame Specs

Tubing: Surly 4130 CroMoly steel. Custom double-butted trumpet tube main triangle. TIG-welded. ED coated.

  • Rear Dropouts: 12mm horizontal and vertical slotted with derailleur hanger and Surly "Gnot-Boost" 135, 142, and/or 148mm hub spacing compatibility.
  • Brake Compatibility: 51mm I.S. disc caliper mounts, 180mm max rotor size
  • Braze-ons/extras: Two down tube bottle-mounts on all sizes (SM-XL), no seat tube bosses.
  • Seatpost Diameter: 30.9mm
  • Seatpost Clamp Diameter: 33.1mm (Surly Stainless included)
  • Headset/Steerer Tube: ZS44/28.6 upper, EC44/30 lower
  • Front Derailleur Clamp Diameter: 34.9mm, high direct-mount
  • Bottom Bracket Shell: 73mm
  • Chainring Clearance: 30t Boost 1x, 24/36t Boost 2x
  • Tire Clearance: 29 x 3.0"
  • Fork: 15mm Thru-Axle, 1-1/8" steerer tube, 203mm disc brake clearance and 29 x 3.0" tire clearance
  • Thru Axle: HU0138 Surly 15x110 Front Thru Axle. HU0134 Surly 12x142/148 Rear Thru Axle
  • Colors: Demonic Sparkle Party, Andy's Apple Red, Dark Black, Pickled Beet Red
