Big Dummy

Big Dummy

Cargo Hauling – 1-2 Passengers - Longtail

Regular price $2,449.00 USD
Regular price $2,449.00 USD Sale price $2,449.00 USD
Sale
Size

Product overview text test

⚠️ WARNING: This product can expose you to chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

View full details

Take Your Longtail Bike Anywhere

Since its introduction in 2008, many a family have ditched one or both of their cars thanks to Big Dummy. We’ve also seen many entrepreneurs and small business owners minimize their carbon footprint and incorporate Big Dummy into their business model.

Big Dummy is a dependable grocery getter, the modern day mini-van, the company car, and a human-powered car replacement. It’s all those things and more in that there’s no limit to what it can haul — as long as it falls within the 400-pound weight limit.

  • Dedicated single-piece frame increases stiffness and decreases torsional flex
  • Human cargo compatible with the use of Dummy Rail Collars
  • Vertical, 135mm spaced dropouts with fender eyelets; Rohloff compatible
  • Clearance for 26" x 2.5" tires with fenders
  • 400-lb. combined rider and cargo weight limit

Specifications

Build Kit

Frameset

Frame

100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded

Color

Bruised Ego Purple

Fork

100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated

Components

Headset

Cane Creek 40

Seatpost Clamp

Surly Stainless 33.1mm

Seatpost

Kalloy 30.9, 350mm

Stem

Kalloy 31.8

Grips/Bar Tape

Velo Black

Saddle

Selle Italia X-Base

Handlebar

Surly Terminal Bar

Drivetrain

Front Derailleur

N/A

Rear Derailleur

microSHIFT Advent 1x9 Speed, RD-M6195M

Cassette

microSHIFT Advent 11-46t, 9-speed

Chain

KMC X10 10-Speed

Crankset

Race Face, 32t

Shifter

microSHIFT Advent Trail 1x9 shifter, SL-M9195-R

Brake Levers

Avid FR-5

Brake Calipers

Avid BB7 S MTN

Bottom Bracket

Race Face

Rotors

SRAM CenterLine 200/180mm

Wheels

Front Tire

Surly ExtraTerrestrial Tire - 26 x 2.5", Tubeless, Folding, Black/Slate, 60tpi (tubes installed)

Rear Tire

Surly ExtraTerrestrial Tire - 26 x 2.5", Tubeless, Folding, Black/Slate, 60tpi (tubes installed)

Front Hub

Novatec QR x 100, 36h

Rear Hub

Novatec QR x 135, 36h

Spoke

DT Swiss 2.0 Stainless

Rim

OE, 38mm, 36h

*Specifications are subject to change without notice

Geometry

Geometry Diagram
SizeSmallMediumLarge
A. Effective Top Tube 590.0 620.0 645.0
B. Stand Over 725.0 773.0 823.0
C. Reach 409.9 431.1 447.2
D. Stack 571.1 599.3 627.4
E. Total Seat Tube Length 406.0 432.0 508.0
F. Headtube Length 150.0 180.0 210.0
G. Headtube Angle
70.0
70.0
70.0
H. Seat Tube Angle
72.5
72.5
72.5
I. BB Drop 40.0 40.0 40.0
K. Chainstay Length 821.0 821.0 821.0
L. Fork Length Axle to Crown 417.8 417.8 417.8
M. Fork Offset 43.0 43.0 43.0
N. Wheelbase 1469.0 1500.4 1526.8
Crank Arm Length 170.0 175.0 175.0
Handlebar Width 718.0 735.0 735.0
Recommended Rider Height 160.0 - 177.8 167.6 - 182.9 177.8 - 195.6
Stem Length 70.0 70.0 80.0

Frame Specs

  • Design Wheel/Tire Sizes 26 x 2.3"
  • Alternate Wheel/Tire Sizes 27.5 x 1.5-2.0" w/ or w/o fenders
    700c x 28-32mm w/ or w/o fenders
  • Frame Construction 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded
  • Fork Construction 100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
  • Suspension Fork Length (Travel) N/A
  • Rigid Fork Length 420mm
  • Fork Offset 43mm
  • Axle to Crown 420mm
  • Rear Spacing 10 x 135mm
  • Front Brake (Rotor) 51mm IS (160-203mm)
  • Headset - Upper EC34
  • Headset - Lower EC34
  • Front Spacing 10 x 100mm
  • Steerer Tube Ø28.6mm (1-1/8")
  • Crown Race Ø30mm (1-1/8")
  • Seatpost Ø30.9mm
  • Dropper Post Compatible Yes
  • Seatpost Clamp Ø33.1mm
  • Max Post Insertion Small: 375mm
    Medium: 255mm
    Large: 331mm
  • Front Derailleur Clamp High direct-mount top-pull (Ø34.9mm)
  • Bottom Bracket 73mm BSA threaded (1.37" x 24TPI)
  • Crankset (Max Ring) No frame limitations
  • Bottle Mounts Small: Two Standard, One 3-pack
    Medium and Large: Three Standard; One 3-Pack
  • Fork Mounts Four 3-Pack, rack mounts: upper, lower, and mid-blade threaded
  • Front Fender Mounts Yes
  • Rear Fender Mounts Yes

Warranty

Frame Warranty

LIMITED WARRANTY

This Surly product is warranted against defects in materials and
workmanship for three years from the date of retail purchase of the
product, subject to the limitations detailed below. Save your dated
receipt for proof of purchase.

This warranty does NOT cover the following:

Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler

Products that have been modified, neglected, used in competition or
for commercial purposes, misused or abused, involved in accidents or
anything other than normal use

Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold

Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product

Normal wear and tear

Labor required to remove and/or refit and re-adjust the product within the bicycle assembly

This limited warranty is expressly limited to the repair or
replacement of a defective product, at the option of Surly, and is the
sole remedy of the warranty. This limited warranty applies only to the
original purchaser of the Surly product and is not transferrable. This
warranty applies only to products purchased through an authorized dealer
or distributor. In no event shall Surly be liable for any loss,
inconvenience or damage, whether direct, incidental, consequential, or
otherwise resulting from breach of any express or implied warranty or
condition, of merchantability, fitness for a particular purpose, or
otherwise with respect to our products except as set forth herein.

This limited warranty gives the consumer specific legal rights, and
those rights and other rights may vary from place to place. This limited
warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE
AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS
INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
