The All-Around Fat Bike
Wednesday sits in the middle of our Trail category, but don’t let that fool you into thinking that’s its only use. With Wednesday, we borrowed elements from some of our Trail and Touring models to create a versatile fat tire trail bike that can truly handle anything you want to attempt.
If you do an equal amount of off-road touring as you do hitting trails, Wednesday’s ability to play both parts equally will suit you well. Or, if you’re looking for a fat bike and don’t need the fattest tires on the market, Wednesday’s 26 x 4.6” tire clearance is just the ticket.
“Any day of the week’s a great day to ride a Wednesday.”
- Modern mountain standards: stealth dropper post routing, 44mm headtube, suspension correction, front and rear thru-axles
- Full suite of useful braze-ons: front and rear racks, multiple sets of three-pack mounts, fenders
- Full-forward, short chainstay position: 26 x 3.8˝ tires on 80mm rims; full-rearward, longer chainstay position: 26 x 4.6˝ tires on an 80mm rim
Specifications
Build Kit
Frameset
Frame
Surly Wednesday, 100% Surly 4130 Chromoly steel. 100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Color
OG Algae
Fork
Surly Wednesday, 100% Surly 4130 Chromoly steel. 100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Components
Headset
Cane Creek
Seatpost Clamp
Stainless 33.1 collar, Black
Seatpost
Promax, 30.9mm, 0 offset
Stem
Promax, 31.8mm
Grips/Bar Tape
Velo Black
Saddle
WTB Volt
Drivetrain
Front Derailleur
N/A
Rear Derailleur
SRAM SX Eagle
Cassette
SRAM PG-1210 Eagle, 11-50t, 12spd
Chain
SRAM SX Eagle
Crankset
SRAM NX Eagle DUB, 30T
Shifter
SRAM SX Eagle
Brake Levers
Tektro HD-M275/276
Brake Calipers
Tektro HD-M275/276
Bottom Bracket
SRAM DUB
Rotors
Tektro 160/160, 6-bolt
Wheels
Front Tire
Surly Nate 26 x 3.8", 60tpi, tubeless ready
Rear Tire
Surly Nate 26 x 3.8", 60tpi, tubeless ready
Front Hub
Novatec 15 x 150mm, 32h, 6-bolt
Rear Hub
Novatec 12 x 177mm, 32h, 6-bolt
Spoke
14G Black
Rim
Surly My Other Brother Darryl
Weight
Complete Bike
36.1 lb for Medium
*Specifications are subject to change without notice
Geometry

Size | X-Small | Small | Medium | Large | X-Large |
---|---|---|---|---|---|
A. Effective Top Tube | 570.0 | 590.0 | 610.0 | 630.0 | 650.0 |
B. Stand Over | 711.0 | 737.0 | 774.0 | 807.0 | 841.0 |
C. Reach | 400.0 | 420.0 | 436.0 | 453.0 | 471.0 |
D. Stack | 573.0 | 578.0 | 587.0 | 597.0 | 606.0 |
E. Total Seat Tube Length | 316.0 | 366.0 | 416.0 | 466.0 | 516.0 |
F. Headtube Length | 95.0 | 100.0 | 110.0 | 120.0 | 130.0 |
G. Headtube Angle |
69.0
|
69.0
|
69.0
|
69.0
|
69.0
|
H. Seat Tube Angle |
73.5
|
73.5
|
73.5
|
73.5
|
73.5
|
I. BB Drop | 55.0 | 55.0 | 55.0 | 55.0 | 55.0 |
K. Chainstay Length | 435.0 | 435.0 | 435.0 | 435.0 | 435.0 |
L. Fork Length Axle to Crown | 468.0 | 468.0 | 468.0 | 468.0 | 468.0 |
M. Fork Offset | 47.0 | 47.0 | 47.0 | 47.0 | 47.0 |
N. Wheelbase | 1081.0 | 1101.0 | 1122.0 | 1143.0 | 1164.0 |
Crank Arm Length | 170.0 | 170.0 | 175.0 | 175.0 | 175.0 |
Handlebar Width | 700.0 | 700.0 | 750.0 | 750.0 | 750.0 |
Recommended Rider Height | 145.0 - 160.0 | 155.0 - 170.0 | 165.0 - 180.0 | 175.0 - 191.0 | 185.0 - 201.0 |
Stem Length | 60.0 | 60.0 | 70.0 | 70.0 | 80.0 |
Frame Specs
- Design Wheel/Tire Sizes 26 x 3.8"
- Frame Construction 4130 Chromoly, Natch tubing, double-butted main triangle, trumpet flared tubes, TIG welded, ED coated
- Fork Construction 4130 Chromoly, Natch tubing, double-butted tapered fork blades, TIG welded, ED coated
- Suspension Fork Length (Travel) 511 x 51mm (Fatbike 100mm)
- Rigid Fork Length 468mm
- Fork Offset 47mm
- Axle to Crown 468mm
- Rear Spacing 12 x 177mm (Surly axle included)
- Front Brake (Rotor) Disc - 51mm I.S. (203mm max rotor)
- Headset - Upper ZS44/28.6
- Headset - Lower EC44/30
- Front Spacing 15 x 150mm (Surly axle included)
- Steerer Tube Ø28.6mm (1-1/8")
- Crown Race Ø30mm (1-1/8")
- Stem Clamp Ø28.6mm (1-1/8")
- Seatpost Ø30.9mm
- Dropper Post Compatible Yes
- Seatpost Clamp Ø33.1mm
- Front Derailleur Clamp (Ø34.9mm)
- Front Derailleur Type High direct mount top-pull
- Bottom Bracket 100mm threaded (1.37" x 24TPI)
- Crankset (Max Ring) 1x (Fat bike 170): 34T / 2x (Fat bike 170): 26/38T / 2x (Surly OD): 22/36T
- Bottle Mounts 2 Standard (XS - M), 3 Standard (L - XXL)
- Fork Mounts 2 Three-Pack, Rack Mounts (upper, lower, and mid-blade threaded)
- Front Fender Mounts N/A
- Rear Fender Mounts Yes
